STOVE DIMENSIONS: 21-1/2″ H x 27-5/8″ W x 22-3/8″ D
STOVE WEIGHT: 460 Lbs
CUBIC FEET FIREBOX VOLUME: 2.15
FIREWOOD LENGTH: 22″ (side to side) 16″(front to back)
ASHPAN: No
FREESTANDING CLEARANCE TO COMBUSTIBLES: 16″ (Corner)* – 23″ (Rear) – 24″ (Side)
EMISSIONS G/H: 1.8
PEDESTAL: YES
MINIMUM FIREPLACE DIMENSIONS: 22-1/2″ H x 27-3/4″ W x 15″
BLOWER: Yes
FLUE SIZE: 6″
EFFICIENCY: 73%
** HEARTH PAD SIZE: 50″ W x 54″ D 34″ W x 48″ D
HEAT CAPACITY: 1500 – 2,600 Sq. Feet
EPA Tested Output BTU/H: 13,300-52,400
MOBILE HOME APPROVED: YES++
** Hearth pad size listed is the minimum size required for vertical vent installations.
++Requires optional outside air pedestal and/or outside air kit for mobile home installations.
