STOVE DIMENSIONS: 29″ H X 23 3/4″ W X 14″ D
STOVE WEIGHT: 460 Lbs
CUBIC FEET FIREBOX VOLUME: 2.48
FIREWOOD LENGTH: 20″ (Front To Back) 18″(Side To Side)
ASHPAN: Yes
FREESTANDING CLEARANCE TO COMBUSTIBLES: 16″ (Corner)* – 23″ (Rear) – 24″ (Side)
EMISSIONS G/H: 1.1
PEDESTAL: YES
MINIMUM FIREPLACE DIMENSIONS: 23-3/4″ H X 29″ W X 14″ D
BLOWER: Yes
FLUE SIZE: 6″
EFFICIENCY: 69.8%
** HEARTH PAD SIZE: 33″ W X 48″ D
HEAT CAPACITY: 1,600 – 2,700 Sq. Feet
EPA Tested Output BTU/H: 13,800-59,500
MOBILE HOME APPROVED: YES++
** Hearth pad size listed is the minimum size required for vertical vent installations.
++Requires optional outside air pedestal and/or outside air kit for mobile home installations.
