Features
- Insulated steel jacket.
- Cast aluminum fire door.
- Cast iron grate and side rails.
- Domestic hot water coil
- Temperature/altitude gauge.
- Boiler temperature operating control.
- Internal coil for domestic hot water.
- Pressure relief valve.
- Large ash pan.
- Large water storage capacity.
- Optional Beckett Oil Burner Dual Fuel Kit.
- ASME Certified
- UL Listed
- Electricity Needed
| MODEL NO. | Total Capacity Square Feet of Radiation | Recommended Load Square Feet of Radiation | B.T.U. per HR TO THE NEAREST THOUSAND | Hopper Capacity lbs. | |||
| STEAM | Hot W. | STEAM | Hot W. | Net | Gross | ||
| KAA-2 | — | 480 | — | 400 | 76 | 90 | 100 |
| KAA-4 | — | 600 | — | 525 | 105 | 120 | 240 |
| KFL-6 | — | 810 | — | 606 | 116 | 132 | 275 |
| KA-6 | 600 | 960 | 420 | 675 | 122 | 144 | 275 |
| KB-8 | 800 | 1280 | 560 | 900 | 163 | 192 | 315 |
| KC-10 | 1000 | 1600 | 700 | 1125 | 204 | 240 | 450 |
| KD-12 | 1200 | 1920 | 840 | 1350 | 245 | 288 | 525 |
| KE-15 | 1500 | 2400 | 1050 | 1690 | 306 | 360 | 525 |
| KF-18 | 1800 | 2880 | 1260 | 2025 | 367 | 432 | 525 |
| KG-22 | 2200 | 3520 | 1540 | 2475 | 448 | 528 | 585 |
| STOKER DATA | Smoke Outlet Size | W | L | H | ||
| Model | No. of Grates 3″ X 14″ | Gallons of Water | ||||
| AA | 3 | 24 | 6″ | 22 ½ | 27 ½ | 36 |
| AA | 3 | 34 | 6″ | 22 | 34 | 47 |
| AA | 3 | 55 | 8″ | 24 | 40 | 52 ½ |
| AA | 3 | 55 | 8″ | 24 | 40 | 52 ½ |
| B | 4 | 74 | 9″ | 29 | 42 | 55 |
| C | 5 | 86 | 10″ | 31 | 44 | 56 |
| D | 6 | 96 | 10″ | 31 | 50 | 55 |
| E | 7 | 122 | 12″ | 33 | 55 | 57 |
| F | 8 | 154 | 12″ | 33 | 54 ½ | 61 |
| G | 9 | 188 | 14″ | 37 | 62 ½ | 61 |
